APC GALAXY VS Uninterruptible Power Supply UPS - 480V Internal modular battery VRLA, 480 V 3 phase, Schneider Electric, 80 kW

Name: APC GALAXY VS Uninterruptible Power Supply UPS - 480V Internal modular battery VRLA, 480 V 3 phase, Schneider Electric, 80 kW
Brand: APC
Price: 30000.00 USD
Availability: InStock

$ 30000^.00

APC-GVSUPS80K0B5GS

MPN #GVSUPS80K0B5GS

Questions⁽²⁾ Answers⁽²⁾

BRAND NEW

Express Shipping

2-6 Days, via DHL, FedEx, EMS, etc.

Reviews

High-Capacity 80 kW Output – Delivers consistent and reliable 400 V 3-phase power, ensuring uninterrupted operation for critical business, industrial, and commercial systems, while supporting high-demand loads efficiently.
Internal Modular VRLA Battery System – Equipped with advanced VRLA Li-Ion batteries in a modular configuration, providing extended runtime, seamless energy backup, and easy scalability for growing power requirements.
Comprehensive Power Protection – Offers robust surge protection, voltage regulation, and emergency power conditioning, safeguarding sensitive equipment from power disturbances, fluctuations, and unexpected outages.
Intelligent Monitoring and Management – Features networked power management, real-time monitoring, and predictive diagnostics to optimize performance, enhance reliability, and allow proactive maintenance.

Package Dimensions

Width: 21.70 in

Height: 77.60 in

Length: 33.30 in

Weight: 250.00 kg

Specifications

Q&A

Warranty

wholesale buying guide

General

Maximum Configurable Power in VA: 80 kVA
Battery Type: Internal modular battery VRLA
Battery Voltage: 480V
End of Discharge Battery Voltage: 384 V DC
Product or Component Type: Uninterruptible power supply (UPS)
Battery power in VAH: 0 VAh runtime
Output voltage tolerance: +/-1% after 50ms
Main Output Voltage: 480 V 3 phase
Main Input Voltage: 480 V 3 phase
Color: White

Tech Specs

IP degree of protection: IP20
Control panel: Touch Screen LCD User Interface
Presentation: Highly efficient, easy-to-deploy 80kW, 480V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. This UPS is for up to 5 smart modular high capacity battery strings, but is supplied without batteries, so you can easily customize the battery runtime. Includes 5x8 start-up service.
Lead time: Usually Ships within 2 Weeks
Provided Equipment: Dust filter Installation manual Integrated network management Start-Up Service EcoStruxure Ready
Dimensions: L (33.3 in) x W (21.7 in) x H (77.6 in)
Weight: 296 kg
Input Frequency: 40 - 70 Hz
Efficiency at full load: 408...552 V 480 V
Input Total Harmonic Distortion: Less than 3% for full load
Load power factor: From 0.7 leading to 0.7 lagging without any derating
Input Power Factor at Full Load: 0.99
Harmonic distortion: Less than 3%
Output Frequency: 50 Hz sync to mains 60 Hz sync to mains
Crest factor: 2.5
Waveform Type: Sine wave
Output Voltage THD: < 1% linear load and < 3% non-linear load
Overload Operation: 10 minutes @ 125% and 60 seconds @ 150%
Standards: CSA C22.2 No 107.3 FCC Part 15 class A IEC 62040-1-1 IEC 62040-2 IEC 62040-3 UL 1778 5th edition OSHPD
Ambient Air Temperature for Operation: 32…104 °F (0…40 °C)
Relative Humidity: 0…95 % non-condensing
Operating altitude: 0...3300 ft
Ambient Air Temperature for Storage: 5…104 °F (-15…40 °C)
Storage Relative Humidity: 10…80 % non-condensing
Storage altitude: 0…10000 ft (0…3048 m)
Acoustic level: 65 dBA
Heat dissipation: 8334 Btu/h
