Cisco Catalyst 9200 Switch - 56 Gbps Switching Bandwidth, 83.33 Mpps Throughput, 24 x PoE+ RJ45 Ports, 4 x SFP (uplink)
Key Features
- Exceptional Network Performance: Offers 56 Gbps switching bandwidth and 83.33 Mpps throughput for fast and reliable data transfer.
- Power-Enabled Ports: Features 24 PoE+ RJ45 ports, supplying both data and power to devices like IP phones and wireless access points.
- Scalable Connectivity: Includes 4 SFP uplink ports for high-speed connections to the core network or additional switches.
- Advanced Memory: Equipped with 2GB RAM and 4GB flash for robust performance and support for advanced network features.
- Comprehensive Routing Support: Manages up to 3,000 IPv4 routing entries and 1,500 additional entries for efficient network routing and scalability.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Ports
- 24 x Gigabit Ethernet (PoE+) RJ45 Ports | 4 x Gigabit SFP (uplink)
- Switching Bandwidth
- 56 Gbps
- Maximum Throughput
- 83.33 Mpps
- Memory (RAM)
- 2 GB
- Flash
- 4 GB
Tech Specs
- Stacking Bandwidth
- 80 Gbps
- Total number of MAC addresses
- 16,000
- QoS Scale Entries
- 1,000
- ACL scale entries
- 1,500
- IPv4 routing entries
- 3,000
- IPv6 routing entries
- 1,500
- Layer Services Supported
- Layer 3
PoE-out
- PoE Capability
- 740 Watts
