CISCO Catalyst C9200L Switch - 392 Gbps Switching Capacity, Throughput up to 291.66 Mpps, 740W PoE Capability, 48 x RJ45, Network Advantage
Express Shipping
out of 5 stars
Key Features
- High Switching Capacity: Provides 392 Gbps switching capacity and throughput up to 291.66 Mpps for high-performance networking, ensuring smooth data handling for large enterprises.
- PoE+ Power: Delivers up to 740W of Power over Ethernet (PoE+), supporting a wide range of powered devices like IP cameras, phones, and access points.
- Flexible Port Configuration: Includes 12 x Fast 2.5G/5G/10GBase-T RJ45 ports and 36 x 1000Base-T RJ-45 PoE+ ports, offering flexible and high-speed connectivity for all network devices.
- Advanced Network Features: Equipped with 2GB of RAM and 4GB of storage, this switch ensures reliable performance and scalability for complex network infrastructures.
- Enhanced Uplink Capability: Features 4 x 10GBase-X uplink ports, providing fast and reliable network connections for high-bandwidth applications and network expansion.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Ports
- 12 x Fast /2.5G/5G/10GBase-T RJ-45 | 36 x 1000Base-T RJ-45 PoE+ | 4 x 10GBase-X uplink | 1 x management (LAN) RJ-45 | 1 x console RJ-45
- Storage size
- 4GB
- Switching Capacity
- 392 Gbps
- Throughput rate
- 291.66 Mpps
- Layer Services Supported
- Layer 2, Layer 3
- Size of RAM
- 2 GB
Powering
- PoE Capability
- 740 Watts
Tech Specs
- MTBF
- 337,360 hours
- Weight
- 5.71 kg
- MAC Address Table
- 16 K
- Operating Temperature
- -5 °C to 45 °C
- Dimensions
- L (13.78 in) × W (17.72 in) × H (1.73 in)
