HPE Aruba CX 6200F (JL727A) Switch - 48 x Gigabit Ethernet BASE-T Class 4 PoE Ports, 4 x 1/10G SFP Ports, 1 x USB-C Console, 1 x OOBM, 1 x USB-A
Key Features
Comprehensive Power over Ethernet: Boasts 48 Gigabit Ethernet BASE-T Class 4 PoE ports, enabling power delivery to connected devices like IP phones and wireless access points.
Flexible Uplinks: Features 4 SFP ports supporting both 1G and 10G connections for scalable network expansion and high-speed uplinks.
Advanced Management Options: Equipped with a USB-C console, USB-A, and an Out-of-Band Management (OOBM) port for simplified administration and device management.
Robust Switching Capacity: Offers 176 Gbps switching bandwidth, ensuring seamless data transmission across all network segments.
IoT Support Ready: Designed to support IoT devices, enhancing network versatility and connectivity for a wide range of applications.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Ports
- 48 x Gigabit Ethernet BASE-T Class 4 PoE Ports | 4 x 1/10G SFP Ports | 1 x USB-C Console Port | 1 x OOBM Port | 1 x USB Type-A Port | 1 x Bluetooth Adapter
- Switching Bandwidth
- 176 Gbps
- CPU
- ARM Cortex A72 (Quad-Core Up to 1.8 GHz)
Tech Specs
- Latency
- 1 Gbps 2.28 μSec | 10 Gbps 1.46 μSec
- Maximum Throughput
- Up to 130.9 Mpps
- Weight
- 5.05 kg
Powering
- Input voltage
- 100V-120V/200V-240V
- Power Consumption
- 76W at 230 VAC
PoE-out
- PoE Capability
- 370W
