HPE Aruba Instant On 1430 (R8R46A) Switch - 8 x Gigabit Ethernet PoE++ Ports RJ45 (100 W, 802.3bt Type 4)
Key Features
8 x Gigabit Ethernet PoE++ Ports: Features 8 RJ45 PoE++ ports offering high-speed Gigabit Ethernet connectivity for connected devices.
PoE++ Support (802.3bt Type 4): Each port delivers up to 100W power through 802.3bt Type 4 PoE++, perfect for powering power-intensive devices like IP cameras, wireless access points, and VoIP phones.
High-Speed Data Transfer: Supports Gigabit data speeds, ensuring fast and seamless communication between connected network devices.
Easy Plug-and-Play Deployment: A simple plug-and-play setup makes it effortless to install without the need for complex configuration, making it ideal for small business environments.
Compact and Reliable: Provides a compact design while delivering enterprise-grade network reliability, offering robust performance in small-to-medium networks.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Bandwidth
- 16 Gb/s
- Certifications
- IEC/EN 60950- 1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC/EN 62368-1, 2nd. & 3rd. Ed., UL 62368-1, 3rd. Ed., CAN/CSA C22.2 No. 62368-1, 3rd. Ed., IEC/EN 60825- 1:2014 Class 1, EN 55032:2015/ CISPR 32, Class A, FCC CFR 47 Part 15: 2018, Class A, ICES-003, Class A, VCCI-32, Class A, EN 55035, CISPR 35, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-11, IEC/EN 61000-3-2, IEC/EN 61000-3-3
- Ports
- 8 x Gigabit Ethernet PoE++ Ports RJ45 (100 W, 802.3bt Type 4)
- Operating Temperature
- 0°C to 40°C, 32°F to 104°F
Tech Specs
- Cooling System
- Passive
- Forwarding rate
- 11.9 Mpps
- PoE Capability
- 64W Class 4 PoE
- Layer Services Supported
- Layer 2
- Weight
- 0.77 kg
Powering
- Input Power
- 120 to 240 VAC, 50 / 60 Hz at 2 A 54 VDC at 1.58 A
