HPE Aruba Instant On 1960 48G 2XGT (JL808A) Switch - 48 x Gigabit Ethernet Ports RJ45, 2 x 10 GbE WAN RJ45, 2 x SFP+ 10 GbE WAN
Express Shipping
out of 5 stars
Key Features
48 x Gigabit Ethernet Ports: Equipped with 48 RJ45 Gigabit Ethernet ports, ensuring high-speed wired connections for various devices, suitable for medium to large networks.
Advanced WAN Connectivity: Features 2 x 10 GbE WAN RJ45 ports and 2 x SFP+ 10 GbE WAN ports for high-performance uplinks, enhancing bandwidth and providing robust data throughput.
Flexible Configuration: Supports a wide range of network configurations, enabling users to tailor their network setup according to specific needs, making it ideal for diverse business environments.
Intuitive Management Interface: Offers an easy-to-use web-based management interface, allowing administrators to efficiently configure and monitor network performance and health in real-time.
Enhanced Security Features: Incorporates advanced security protocols to safeguard network data, providing robust protection against unauthorized access and ensuring a secure network environment.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Bandwidth
- 176 Gb/s
- Ports
- 48 x Gigabit Ethernet Ports RJ45 | 2 x 10 GbE WAN RJ45 | 2 x SFP+ 10 GbE WAN
- CPU
- Single-Core: Up to 800 MHz Cortex A9
- Operating Temperature
- 0-40°C, 0-10,000 ft
Tech Specs
- Cooling System
- Passive
- Forwarding rate
- 131 Mpps
- Layer Services Supported
- Layer 2
- Weight
- 4.4 Kg
Powering
- Input Power
- 100 to 240 VAC, 50 / 60 Hz at 0.4 to 1.1 A
