Mikrotik hAP ax³ (C53UiG+5HPaxD2HPaxD) Wireless Access Point - Wireless for Home and Office, 4 x Gigabit Ethernet, PoE in and PoE out, Dual-Band support
Key Features
Specifications
Q&A
Warranty
wholesale buying guide
General
- Certifications
- CE, FCC, IC, EAC, ROHS
- Storage size
- 128 MB
- Wireless 2.4 GHz Max data rate
- 574 Mbit/s
- Wireless 2.4 GHz standards
- 802.11b/g/n/ax
- Wireless 2.4 GHz generation
- Wi-Fi 6
- CPU core count
- 4
- Wireless 5 GHz Max data rate
- 1200 Mbit/s
- Wireless 5 GHz standards
- 802.11a/n/ac/ax
- Wireless 5 GHz generation
- Wi-Fi 6
- Antenna gain dBi for 5 GHz
- 5.5
- Antenna gain dBi for 2.4 GHz
- 3.3
- Operating System
- RouterOS
- Ports
- 4 x Gigabit Ethernet | 1 x Gigabit Ethernet ports with PoE-out | 1 x 2.5 Gigabit Ethernet | 1 x USB 3.0 type A | USB Power Reset | PoE in and PoE out
- Ambient temperature
- -40C to +70C
- CPU
- IPQ-6010
- Size of RAM
- 1 GB
Tech Specs
- Storage type
- NAND
- IP
- 20
- Architecture
- ARM 64bit
- Wireless 5 GHz number of chains
- 2
- WiFi speed
- AX1800
- CPU nominal frequency
- auto (864 - 1800) MHz
- RouterOS license
- 6
- Max Transmit power of 5 GHz
- 28 dBm
- Max Transmit power of 2.4 GHz
- 27 dBm
- Wireless 2.4 GHz number of chains
- 2
- MTBF
- Approximately 200'000 hours at 25C
Powering
- Cooling type
- Passive
- Number of DC inputs
- 2 (DC jack, PoE-IN)
- DC jack input Voltage
- 12-28 V
- PoE in input Voltage
- 18-28 V
- Max power consumption
- 38 W
- Max power consumption without attachments
- 15 W
- Number of DC inputs
- 1 (PoE-IN)
- PoE in
- Passive PoE
PoE-out
- PoE-out ports
- Ether 1
- Max out per port output (input 18-30 V)
- 0.625 A
- Max total out (A)
- 0.625 A
- Total output current
- 0.625
- Total output power
- 15
- PoE out
- Passive PoE
| Products |
|---|
| Choose your plan |
- Desktop | Wall Mountable | Rack-mountable
- 10 Gbps
- Yes
- 48 x Smart Rate 100M/1G/2.5G/5G BaseT Class 8 PoE Ports supporting up to 90W per port | 2 x 10G/25G/50G SFP Ports | 2 x 10G/25G SFP Ports | 1 x USB‑C Console Port | 1 x RJ Console Port | 1 x OOBM port | 1 x USB-A Port
- 780 Gbps
- 580 Mpps
- Layer 2, Layer 3
- 202.38 Mpps
- 272 Gbps
- 1/2.8" Progressive Scan CMOS
- 2MP (1920 x 1080)
- Up to 30 m IR cut filter
- Wi-Fi 5
- Wi-Fi 5
- -10 to 70° C (14 to 158° F)
Brand New
Fortinet FortiGate 81F NGFW Manageable Firewall - 10 Gbps Firewall Throughput, AES (256-bit), SHA-256, 200 VPN, 10 x RJ45 Ports, 2 x Expansion Slots
