MikroTik Netpower 16P (CRS318-16P-2S+OUT) Switch - Outdoor, 16 x Gigabit Ethernet ports, 16 x 1G Ethernet ports with PoE-out, 2 x SFP+ ports
Key Features
Comprehensive Port Options: Features 16 Gigabit Ethernet ports, along with 2 SFP+ ports, providing extensive connectivity for various networking needs, from simple home setups to complex enterprise solutions.
Power over Ethernet (PoE) Capability: Each of the 16 Ethernet ports supports PoE-out, allowing you to power devices like IP cameras, wireless access points, and VoIP phones directly through the network cable, simplifying installation and reducing the need for additional power supplies.
Designed for Outdoor Use: Built specifically for outdoor applications, the MikroTik Netpower 16P is housed in a rugged enclosure that protects against environmental factors, ensuring reliable performance in varying weather conditions.
High-Speed Fiber Connectivity: The inclusion of 2 SFP+ ports enables high-speed fiber connections, facilitating data transfer rates up to 10 Gbps for improved network efficiency and speed, especially beneficial in high-demand environments.
User-Friendly Management: MikroTik's intuitive RouterOS provides robust management features, allowing for easy configuration and monitoring of network performance, ensuring seamless operation and maintenance for both novice and experienced users
Specifications
Q&A
Warranty
wholesale buying guide
General
- CPU
- 98DX226S
- Operating System
- RouterOS / SwitchOS
- Ambient temperature
- -40°C to 70°C
- CPU core count
- 1
- Storage size
- 16 MB
- Ports
- 16 x Gigabit Ethernet ports | 16 x 1G Ethernet ports with PoE-out | 2 x SFP+ ports
- Certifications
- CE, EAC, ROHS
- Size of RAM
- 256 MB
Tech Specs
- CPU nominal frequency
- 800 MHz
- RouterOS license
- 5
- Cooling type
- Passive
Powering
- Number of DC inputs
- 2 (DC jack)
- DC jack input Voltage
- 18-30 V / 48-57 V
- Max power consumption
- 316 W
- Max power consumption without attachments
- 16 W
PoE-out
- PoE in
- 802.3af/at
- PoE-out ports
- Ether1-Ether16
- Max out per port output (input 18-30 V)
- 1.1 A
- Max out per port output (input 30-57 V)
- 0.6 A
- Max total out (A)
- 2.8A (18V-30V) & 1.4A (48V-57V) x2 A
| Products |
|---|
| Choose your plan |
- 2 GB
- 12 x Fast /2.5G/5G/10GBase-T RJ-45 | 36 x 1000Base-T RJ-45 PoE+ | 4 x 10GBase-X uplink | 1 x management (LAN) RJ-45 | 1 x console RJ-45
- 4GB
- 9.2 Gbps
- 6.844 Mpps
- 16 x Fast Mbps RJ45 Ports | 2 x Gigabit RJ45 Ports | 1 x Gigabit SFP Slots
- CE, FCC, IC
- 4 x Gigabit Ethernet RJ45 | 4 x Gigabit Ethernet RJ45 PoE+ (30 W, 802.3at)
- 16 Gb/s 8 Gb/s (Non-Blocking)
- ARM Cortex-A72 (Quad-Core 1.8GHz)
- 8 GB DDR4
- 32GB eMMC
- 14 Gbit/s
- 10.5 Mpps
- 4 x Gigabit Ethernet Ports | 1 x SFP Port
- 52 Gbps
- 38.68 Mpps
- 24 x Gigabit RJ45 Ports | 1 x Gigabit RJ45 PoE Ports
- 48 x Gigabit Ethernet Ports Ports | 4 x SFP+ or 2 x 40GbE ports uplink with optional module, 1 x RJ45 Console | 1 x Micro-USB Console | 1 x USB-A
- ARM Cortex A9 (Dual core 1GHz)
- 2GB DDR3
CISCO Catalyst C9200L Switch - 392 Gbps Switching Capacity, Throughput up to 291.66 Mpps, 740W PoE Capability, 48 x RJ45, Network Advantage
Cudy FS1018PS1 Switch - 9.2 Gbps Switching Capacity, Throughput up to 6.844 Mpps Mpps, 16 x RJ45 Ports
Ubiquiti UniFi LITE 8 POE (USW-LITE-8-POE) Switch - 4 x Gigabit Ethernet Ports RJ45, 4 x Gigabit Ethernet PoE+ RJ45 (30 W, 802.3at)
HPE Aruba CX 6300F (JL666A) Switch - 24 x Gigabit Ethernet BaseT Ports, 4 x 1G/10G/25G/50G SFP Ports, 1 x USB‑C Console, 1 x OOBM, 1 x USB-A
