Ruijie (RG-S5310-24GT4XS-P-E) Switch - 24 x Gigabit Ethernet ports BASE-T ports, 4 x 1GE/10GE SFP+ ports, 1 x RJ45 console port, 1 x RJ45 MGMT port
Key Features
Efficient Port Density: Offers 24 x Gigabit Ethernet BASE-T ports, ensuring high-speed data transfer for medium-sized network environments with reliable connectivity.
Flexible Uplink Capabilities: Comes with 4 x 1GE/10GE SFP+ uplink ports, providing enhanced performance for uplinks, data aggregation, and inter-switch connections at 10Gbps speeds.
Power-over-Ethernet: Supports PoE+, enabling the switch to power various devices like IP cameras, wireless access points, and VoIP phones without the need for additional power supplies.
Comprehensive Management: Equipped with 1 x RJ45 console port and 1 x RJ45 MGMT port, the switch offers easy management options for configuration and monitoring via the console or web interfaces.
Enterprise-Grade Reliability: Built for robust performance, the Ruijie switch delivers reliable and secure network operations, making it ideal for enterprises and institutions requiring scalable and dependable networking solutions.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Ports
- 24 x Gigabit Ethernet ports BASE-T ports | 4 x 1GE/10GE SFP+ ports PoE/PoE+ | 1 x RJ45 console port | 1 x RJ45 MGMT port
- Switching Bandwidth
- 154 Gbps
- Tested ambient temperature
- 0°C to 45°C (32°F to 113°F)
- Storage size
- 2GB
- Size of RAM
- 1GB
Tech Specs
- Weight
- 4.3 kg
Powering
- Power Consumption
- 65 W (without PoE load) | 810 W (full PoE load)
PoE-out
- PoE Capability
- 740 Watts
| Products |
|---|
| Choose your plan |
- 24 x Gigabit Ethernet Ports RJ45, 4 x SFP+ 10 GbE WAN, 1 x RJ45, 1 x Micro-USB
- 128 Gb/s
- 4GB
- 18.6 - 19.1 dBi
- 200 km/h (125 mph)
- 16 x Gigabit Ethernet RJ45 | 2 x SFP Gigabit Ethernet
- 32 Gb/s
- 32 to 104°F / 0 to 40°C
- 48 x Gigabit Ethernet BASE-T Class 4 PoE Ports | 4 x 1/10G SFP Ports | 1 x USB-C Console Port | 1 x OOBM Port | 1 x USB Type-A Port | 1 x Bluetooth Adapter
- 176 Gbps
- ARM Cortex A72 (Quad-Core Up to 1.8 GHz)
- ARM Cortex A9 (Dual-Core Up to 1016 MHz)
- 48 x Gigabit Ethernet PoE+ (30 W, 802.3at) Ports RJ45 | 4 x SFP+ 10 GbE WAN | 1 x RJ45 LAN | 1 x Micro-USB | 1 x USB-A
- 320 Mb/s
- 104 Gb/s
- ARM Cortex A9 (Dual-Core Up to 1016 MHz)
- 1GB DDR3
HPE Aruba 2930F (JL253A) Switch - 24 x Gigabit Ethernet Ports RJ45, 4 x SFP+ 10 GbE WAN, 1 x RJ45, 1 x Micro-USB
Ubiquiti UISP (AM-5G19-120) Antenna - Point to MultiPoint, Outdoor 5 GHz, 19.4 - 20.3 dBi
TP-LINK TL-SG3216 Switch - 16 x Gigabit Ethernet RJ45, 2 x SFP Gigabit Ethernet
