Ruijie (RG-S6120-20XS4VS2QXS) Switch - 20 x 1GE 2.5GE 10GE SFP+ Ports, 4 x 10GE 25GE SFP28 Ports, 2 x 40GE QSFP+ Ports, 1 x RJ45 Console Port, 1 x RJ45 OOBM Port, 1 x USB Port
Key Features
Versatile Port Configuration: Equipped with 20 x 1GE/2.5GE/10GE SFP+ ports, this switch supports a wide range of connectivity options to accommodate various network speeds and devices.
High-Speed Uplinks: Features 4 x 10GE/25GE SFP28 ports and 2 x 40GE QSFP+ ports for ultra-fast uplink connections, enabling efficient data transfer for high-bandwidth applications.
Comprehensive Management Options: The inclusion of 1 x RJ45 console port, 1 x RJ45 Out-Of-Band Management (OOBM) port, and 1 x USB port allows for easy device management and configuration, enhancing operational flexibility.
Robust Performance: Designed for high-performance networking, this switch ensures minimal latency and maximizes throughput, making it ideal for data centers and enterprise environments.
Scalable and Future-Ready: The combination of multi-speed ports and advanced technology enables seamless scalability, ensuring the switch can meet growing network demands and adapt to future upgrades.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Bandwidth
- 912 Gbps
- Tested ambient temperature
- 0°C to 50°C (32°F to 122°F)
- Storage size
- 1GB
- Ports
- 20 x 1GE 2.5GE 10GE SFP+ Ports | 4 x 10GE 25GE SFP28 Ports | 2 x 40GE QSFP+ Ports | 1 x RJ45 console Port | 1 x RJ45 OOBM Port | 1 x USB Port
- Size of RAM
- 1GB
Tech Specs
- Slot
- 2 x power module slots | 2 x fan
- Weight
- 4.6 kg
Powering
- Maximum Power Consumption
- 85 Watts
