CISCO Catalyst C1200 Managed Switch - 20 Gbps Switching Capacity, Throughput up to 14.88 Mpps, 120W PoE Capability, 8 x RJ45, 2 x Combo
Key Features
- High-Speed Performance: 20 Gbps switching capacity and throughput of up to 14.88 Mpps for efficient data processing.
- Power over Ethernet (PoE): 120W PoE capability to support PoE+ powered devices such as phones, cameras, and wireless access points.
- Flexible Port Configuration: 8 x Gigabit Ethernet RJ45 ports and 2 x Combo ports (Gigabit Ethernet/SFP) for versatile connectivity options.
- Reliable Hardware: Equipped with 1GB RAM and 512MB storage for improved performance and stable operation.
- Layer 2 Switching: Managed switch with advanced features such as VLAN support, traffic segmentation, and network monitoring for optimized network management.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Capacity
- 20 Gbps
- Forwarding rate
- 14.88 Mpps
- Storage size
- 512 MB
- Ports
- 8 x Gigabit Ethernet Ports | 2 x Gigabit Ethernet combo | 1 x RJ-45 console | 1 x USB Type C management
- Layer Services Supported
- Layer 2
- Size of RAM
- 1 GB
Tech Specs
- MTBF
- 1,706,649 hours
- Weight
- 1.53 kg
- MAC Address Table
- 8 K
- Operating Temperature
- -5 °C to 50 °C
- Dimensions
- L (10.55 in) x W (10.55 in) x H (1.73 in)
Powering
- PoE Capability
- 120 Watts
