HPE Aruba 2930F (JL256A) Switch - 48 x Gigabit Ethernet port PoE+ ports RJ-45, 4 x SFP+ 1/10GbE ports, 1 x serial (console), 1 x Micro-USB
Key Features
High Power Delivery: Equipped with 48 x Gigabit Ethernet PoE+ RJ-45 ports, this switch supports Power over Ethernet, providing up to 30W per port to power devices such as IP cameras, phones, and access points directly through the Ethernet connection.
Flexible Uplink Options: The switch features 4 x SFP+ 1/10GbE ports for high-speed uplink connections, allowing for scalable and efficient integration with other network devices and enhancing overall network performance.
Robust Management Capabilities: Designed for seamless network management, the HPE Aruba 2930F series supports Web-based GUI, CLI, and SNMP, providing users with multiple management options for efficient configuration and monitoring.
Enhanced Security Features: Built with advanced security protocols, including 802.1X authentication and Access Control Lists (ACLs), ensuring secure access to network resources and protecting against unauthorized access.
Versatile Connectivity Options: Offers multiple connectivity options with 1 x serial console port for direct management and 1 x Micro-USB port, making it easy to connect for initial setup or troubleshooting in various environments.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Bandwidth
- 176 Gb/s
- CPU
- ARM Cortex A9 (Dual-Core Up to 1016 MHz)
- Ports
- 48 x Gigabit Ethernet port PoE+ ports RJ-45, 4 x SFP+ 1/10GbE ports, 1 x serial (console), 1 x Micro-USB
- Storage size
- 4GB eMMC
- Size of RAM
- 1GB DDR3
- Operating Temperature
- 32 °F Min | 113 °F Max
Tech Specs
- Latency
- 1000 Mb Latency < 3.8 µs | 10 Gbps Latency < 1.6 µs
- Weight
- 4.46 kg
Powering
- Max power consumption
- 59 W
PoE-out
- PoE Capability
- 370 W PoE+
