HPE Aruba 2930F (JL260A) Switch - 48 x Gigabit Ethernet Ports RJ45, 4 x SFP Gigabit Ethernet Ports, 1 x RJ45 LAN,1 x Micro-USB LAN
Key Features
Comprehensive Connectivity: Offers 48 x Gigabit Ethernet RJ45 ports, providing extensive, high-speed connectivity for large networks with reliable data transfer across multiple devices.
Advanced Uplink Options: Equipped with 4 x SFP Gigabit Ethernet ports, ensuring flexible uplink connectivity options for both fiber and high-speed Ethernet applications.
Simplified Management: Includes 1 x RJ45 LAN and 1 x Micro-USB LAN, enabling straightforward device configuration and management, essential for streamlined network administration.
Enterprise-Level Performance: Designed for business-critical environments, the HPE Aruba 2930F delivers consistent, high-speed performance, ensuring smooth operations for enterprise networks.
Scalable and Efficient: Ideal for growing infrastructures, this switch supports network scalability, offering efficient and future-proof solutions for expanding business needs.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Bandwidth
- 104 Gb/s
- CPU
- ARM Cortex A9 (Dual-Core Up to 1016 MHz)
- Ports
- 48 x Gigabit Ethernet Ports RJ45 | 4 x SFP Gigabit Ethernet Ports | 1 x RJ45 LAN | 1 x Micro-USB LAN
- Storage size
- 4GB
- Size of RAM
- 1GB DDR3
- Operating Temperature
- 32 to 113°F / 0 to 45°C
Tech Specs
- Cooling System
- Fan
- Layer Services Supported
- Layer 2, Layer 3
- Weight
- 3.08 kg
Powering
- Input Power
- 100 to 240 VAC, 50 / 60 Hz at 0.6 to 0.9 A
- Power Supply Type
- Internal
- Max power consumption
- 46.6 W
- Latency
- 1000 Mb Latency < 3.8 µs
