HPE Aruba CX 6300M (R8S91A) Switch - 720 Gbps Switching Bandwidth, 535 Mpps Throughput, 2880 W PoE capability, 48 x RJ45
Key Features
High-Speed Switching Bandwidth: Delivers a substantial 720 Gbps switching capacity for seamless, high-performance networking.
Strong Throughput Performance: Handles up to 535 Mpps, ensuring efficient data flow for enterprise applications.
Robust PoE Support: 2880 W PoE capability allows power delivery to a wide array of devices, like IP cameras and wireless access points.
Flexible Connectivity Options: Equipped with 48 RJ45 ports, two 10G/25G/50G SFP ports, and two 1G/10G SFP ports with LRM and MACsec support for secure uplinks.
Comprehensive Management Ports: Includes a USB-C console, RJ45 console, OOBM, and USB-A port for diverse management and configuration needs.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Ports
- 48 x Smart Rate 100M/1G/2.5G/5G BaseT Class 8 PoE ports supporting up to 90W per port on ports 1‑12, and up to 60W per port on ports 13‑48 (MACsec) | 2 x 10G/25G/50G SFP Ports | 2 x 1G/10G SFP ports (LRM + MACsec) | 1 x USB‑C Console Port | 1 x RJ Console Port | 1 x OOBM Port | 1 x USB-A Port
- Switching Bandwidth
- 720 Gbps
- Maximum Throughput
- 535 Mpps
- CPU
- ARM Cortex-A72 (Quad-Core 1.8GHz)
- Storage size
- 32GB eMMC
Tech Specs
- Latency
- 1Gbps to 4.24μSec | 10Gbps to 1.50μSec | 25Gbps to 2.91μSec | 50Gbps1 to 3.49μSec
- Weight
- 6.71 kg
Powering
- Input voltage
- JL670A PSU (110V-120V/208V-240V) | JL086A PSU (100V-240V) | JL087A PSU (110V-240V)
- Power Consumption
- JL086A PSU (Idle 207W, 100% Traffic Rate 283W) | JL087A PSU (Idle 208W, 100% Traffic Rate 282W) | JL670A PSU (Idle 211W, 100% Traffic Rate 283W)
PoE-out
- PoE Capability
- Max PoE Power (2880W)
