MikroTik LHG XL 2 (RBLHG-2nD-XL) Point to Point - Wireless Outdoor, 1 x Fast Ethernet port, PoE-in 2.4 GHz Band support
Key Features
Long-Range Wireless Connectivity: The MikroTik LHG XL 2 is optimized for long-distance point-to-point wireless communication, providing a reliable link between two locations over extended ranges.
2.4 GHz Band Support: Operating on the 2.4 GHz frequency band, this device ensures wide coverage with minimal interference, making it ideal for outdoor wireless setups in rural or remote areas.
Rugged Outdoor Design: Built to withstand harsh weather conditions, this wireless outdoor device is equipped with a durable enclosure that ensures consistent performance in challenging environments.
Fast Ethernet and PoE-In: Featuring 1 x Fast Ethernet port and PoE-in support, it simplifies installation by allowing both data and power to be transmitted over a single cable, reducing the need for additional wiring.
MikroTik Proprietary Technology: Powered by MikroTik's advanced networking solutions, the LHG XL 2 delivers efficient, low-latency performance, perfect for extending wireless networks or establishing point-to-point connections across significant distances.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Certifications
- CE, FCC, IC, EAC, ROHS
- CPU
- QCA9533
- Operating System
- RouterOS
- Wireless 2.4 GHz Max data rate
- 300 Mbit/s
- Wireless 2.4 GHz standards
- 802.11b/g/n
- Wireless 2.4 GHz generation
- Wi-Fi 4
- Antenna gain dBi for 2.4 GHz
- 21
- Ambient temperature
- -40°C to 70°C
- CPU core count
- 1
- Storage size
- 16 MB
- Ports
- 1 x Fast Ethernet port
- Size of RAM
- 64 MB
Tech Specs
- Cooling type
- Passive
- RouterOS license
- 3
- CPU nominal frequency
- 650 MHz
- PoE in
- Passive PoE
- Wireless 2.4 GHz number of chains
- 2
- Max Transmit power of 2.4 GHz
- 25 dBm
Powering
- Number of DC inputs
- 1 (PoE-IN)
- Max power consumption
- 5 W
- PoE in input Voltage
- 10-30 V
