Mikrotik LHGG LTE6 kit RBLHGGR&R11e-LTE6 - powerful 17 dBi ANTENNA
$ 262.80
MPN #RBLHGGR&R11e-LTE6
Key Features
The LHGG LTE6 kit (product code: RBLHGGR&R11e-LTE6) is a powerful router with ARM 64bit architecture and a CPU core count of 2. It has a large size of 391 x 391 x 237 mm and runs on RouterOS operating system with 256 MB of RAM and 16 MB of FLASH storage. It supports 2G, 3G, and LTE networks with a maximum download speed of 300Mbit/s and an upload speed of 50Mbit/s. The router has 1 Ethernet port and 1 SIM slot and supports PoE-in input voltage of 12-57 V. It comes with a Mode button and is certified for CE, EAC, ROHS, and has an IP 54 rating for durability.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Architecture
- ARM 64bit
- CPU
- 88F3720
- Memory Slots
- 2
- CPU nominal frequency
- 800 MHz
- RouterOS license
- 3
- Operating System
- RouterOS
- L3 Cache
- 16 MB
- Storage type
- FLASH
- Number of DC inputs
- 1 (PoE-IN)
- Max power consumption
- 8 W
- Max power consumption without attachments
- 8 W
- Cooling type
- Passive
- PoE in
- 802.3af/at
- PoE in input Voltage
- 12-57 V
- 2G Category
- Class12
- 2G bands
- 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
- 3G Category
- R7 (21Mbps Downlinks, 5.76Mbps Uplink) / R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
- 3G bands
- 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz)
- LTE Category
- 6 (300Mbit/s Downlink, 50Mbit/s Uplink)
- LTE FDD bands
- 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 5 (850MHz) / 12 (700MHz) / 17 (700MHz) / 25 (1900MHz) / 26 (850MHz)
- 10/100/1000 Ethernet ports
- 1
- MiniPCI-e slots
- 1
- Touchscreen
- Yes
- IP
- IP 54
- Ambient temperature
- -30°C to 70°C
- Certifications
- CE, EAC, ROHS
- MTBF
- Approximately 200'000 hours at 25C
- Memory (RAM)
- 256MB
- Dimensions
- 391 x 391 x 237 mm
- Color
- Silver
- Graphic (GPU)
- Intel Iris Xe Graphics
