- Wireless Standards
- IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- External Power Supply
- 9V/0.85A
- Interface
- 4 10/100Mbps RJ45 Ports, 1 RJ11 Port
- Button
- 1 Power On/Off Switch, 1 WPS Button, 1 Wi-Fi On/Off Button
- IEEE Standards
- IEEE 802.3, 802.3u
- ADSL Standards
- Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs), ITU-T G.995.1
- ADSL2 Standards
- ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.4 (G.lite.bis)
- ADSL2 Standards
- ITU-T G.992.5
- Dimensions (WxDxH)
- 7.7*5.1*1.4 inch ( 195*130*35 mm )
- Antenna Type
- Omni directional, Detachable, Reverse SMA
- Antenna gain
- 2x5dBi
- Frequency
- 2.400-2.4835GHz
- Transmit Power
- <20dBm(EIRP)
- Wireless Security
- Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, Wireless MAC Filtering
- Quality of Service
- QoS Remarking based on IPP/ToS, DSCP and 802.1p
- Security
- NAT Firewall, SPI Firewall, MAC / IP / Packet / Application / URL Filtering, Denial of Service(DoS), SYN Flooding, Ping of Death
- Management
- Web Based Configuration(HTTP), Remote management, Telnet management, Command Line Interface, SSL for TR-069, SNMP v1/2c, SNMP over EOC, Web Based Firmware Upgrade, CWMP(TR-069), Diagnostic Tools
- port forwarding
- Virtual server, DMZ, ACL(Access Control List)
- VPN Pass-through
- PPTP, L2TP, IPSec Pass-through
- Environment
- Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
- Certifications
- FCC, RoHs
