TP-Link TL-SG2008 V3 JetStream 8-Port Gigabit Smart Switch
MPN #TL-SG2008
Key Features
TP-Link TL-SG2008 Smart Switch Features
- Full Gigabit Ports: 8× gigabit RJ45 ports provide high-speed connections.
- Integrated into Omada SDN: Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Robust Security Strategies: 802.1Q VLAN, ACL, Port Security, Storm Control, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
- Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Packet Forwarding Rate
- 11.9 Mpps
- Fan Quantity
- Fanless
- Bandwidth
- 16 Gbps
- Network Media
- • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
- Ports
- 8 x Gigabit Ethernet (Auto-Negotiation/Auto MDI/MDIX)
- What is in Box
- • TL-SG2008 • Power Adapter • Installation Guide • Rubber Feet
- Ports
- 8 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
- system requirements
- Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, 10, MAC® OS, NetWare®, UNIX® or Linux.
- Standards and Protocols
- IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
- Cloud Access
- Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
- What is in Box
- • TL-SG2008P • Power Adapter • Installation Guide • Rubber Feet
- Certifications
- CE, FCC, RoHS
- Power Supply
- 12 VDC/1 A External Adapter or, Obtain Power from PoE Source
- Power Consumption
- 6.4 W (220 V/50 Hz)
- MAC Address Table
- 8K
