APC GALAXY VS Uninterruptible Power Supply UPS - 40KW 400V External battery system Li-Ion (Lithium Ion) VRLA, 400 V 3 phase, 480-576VDC Battery Voltage, Schneider Electric
Key Features
High-Capacity Backup Power – Delivers 40kW / 40kVA uninterruptible power for critical business, data centers, and industrial applications.
-
Flexible Battery Technology – Supports Li-Ion and VRLA external batteries with 480–576VDC voltage for extended runtime and reliability.
-
Stable 400V 3-Phase Output – Ensures consistent power delivery and excellent power conditioning for sensitive equipment.
-
Comprehensive Power Management – Provides surge protection, emergency backup, and network equipment support for routers, switches, and access points.
Trusted Schneider Electric Ownership – Schneider Electric aims to achieve net zero by 2050 through supply chain partnerships, less harmful materials and circularity through an ongoing campaign to “Use Better, Use Longer, Reuse” to extend product lifespan and recyclability.
Package Dimensions
Specifications
Q&A
Warranty
wholesale buying guide
General
- Product or Component Type
- Uninterruptible power supply (UPS)
- Battery power in VAH
- 0 VAh runtime
- End of Discharge Battery Voltage
- 307 V DC
- Main Input Voltage
- 380 V 415 V
- Output Voltage THD
- < 1% linear load and < 5% non-linear load
- Output voltage tolerance
- +/-1% after 50ms
- Battery Voltage
- 384-576VDC
- Main Output Voltage
- 400 V 3 phase
- Maximum Configurable Power in VA
- 40 kVA
- Color
- White
Packing Units
- Package Height
- 37.6 cm
- Package Width
- 32.8 cm
- Package Length
- 59.5 cm
Tech Specs
- Output Frequency
- 50 Hz sync to mains 60 Hz sync to mains 50 Hz +/- 0.1 % for 50 Hz nominal not synced 60 Hz +/- 0.1 % for 60 Hz nominal not synced
- Crest factor
- 2.5
- Waveform Type
- Sine wave
- Output voltage tolerance
- +/-1% after 50ms
- Bypass type
- Built-in Static Bypass
- Standards
- EN/IEC 62040-1 EN/IEC 62040-2 FCC Part 15 class A IEC 60721-4-2 Level 2M2 UL 1778 5th edition
- Ambient Air Temperature for Operation
- 32…104 °F (0…40 °C)
- Relative Humidity
- 0…95 % non-condensing
- Operating altitude
- 0...3300 ft
- Ambient Air Temperature for Storage
- -13…131 °F (-25…55 °C)
- Acoustic level
- 68 dBA
- IP degree of protection
- IP21
- Control panel
- Touch Screen LCD User Interface
- Under ownership
- Schneider Electric
