HPE Aruba 6200F (JL728A) Switch - 48 x Gigabit Ethernet PoE+ Ports RJ45, 4 x SFP+ 10 GbE WAN, 2 x USB, 1 x RJ45 LAN OOBM Ports
Express Shipping
out of 5 stars
Key Features
Extensive PoE+ Connectivity: Equipped with 48 x Gigabit Ethernet PoE+ RJ45 ports, the switch provides ample power (up to 30W per port) to support a wide range of PoE devices such as IP cameras, wireless access points, and VoIP phones.
High-Speed Uplinks: The 4 x SFP+ 10 GbE WAN ports offer fast uplink speeds, ensuring high-performance data transfer for demanding applications and providing future-proofing for evolving network needs.
Flexible USB Support: Includes 2 x USB ports (1 x USB-A and 1 x USB-C) for efficient device management, firmware upgrades, and easy access to configurations, simplifying network administration.
Out-of-Band Management: The dedicated RJ45 LAN OOBM port enables secure and independent network management, allowing for system monitoring and troubleshooting without affecting main traffic.
Optimized for Scalability: Designed for flexible deployment, the HPE Aruba 6200F switch supports both small-to-medium businesses and large enterprises, offering seamless scalability and robust network performance.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Bandwidth
- 176 Gb/s
- Ports
- 48 x Gigabit Ethernet PoE+ Ports RJ45 (30 W, 802.3at) | 4 x SFP+ 10 GbE WAN | 1 x USB-A | 1 x USB-C Console Port | 1 x RJ45 LAN OOBM
- CPU
- ARM Cortex A72 (Quad-Core Up to 1.8 GHz)
- Storage size
- 16GB
- Certifications
- EN, UL, IEC, CAN, FCC, VCCI, ICES
- Size of RAM
- 8GB DDR4
Tech Specs
- Cooling System
- Fan
- Latency
- 1 Gbps 2.28 μSec | 10 Gbps 1.46 μSec
- Layer Services Supported
- Layer 2, Layer 3
- Weight
- 5.1 Kg
Powering
- Power Supply Type
- Internal
- Max power consumption
- 76W at 230 VAC
- Input Power
- 100V-120V/200V-240V
PoE-out
- PoE Capability
- 740W
