HPE Aruba CX 6300M (JL661A) Switch - 48 x Gigabit Ethernet PoE+ Ports RJ45, 4 x SFP 50 GbE WAN, 2 x USB, 1 x RJ45 LAN OOBM port
Key Features
Extensive Power Over Ethernet Support: The switch is equipped with 48 x Gigabit Ethernet PoE+ RJ45 ports, delivering up to 30W per port to power various devices, including IP cameras, phones, and wireless access points, thus streamlining device management and reducing cabling requirements.
High-Speed WAN Connectivity: Featuring 4 x SFP 50 GbE WAN ports, this switch provides exceptional throughput for high-bandwidth applications, ensuring seamless data transfer and enhanced network performance, ideal for enterprise environments with demanding data requirements.
Flexible USB Interfaces: The 2 x USB ports (1 x USB-C and 1 x USB-A) offer convenient options for configuration management, firmware upgrades, and data backup, making it easier for IT teams to maintain and optimize network operations.
Dedicated Out-of-Band Management: With a dedicated RJ45 LAN OOBM port, network administrators can manage the switch separately from the data traffic, ensuring that management tasks can be performed securely and without disrupting network operations.
Robust and Scalable Design: The HPE Aruba CX 6300M is designed for scalability, making it suitable for a wide range of applications from small to large enterprises, while its advanced features ensure high performance, reliability, and ease of integration into existing network infrastructures.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Switching Bandwidth
- 496 Gb/s
- Storage size
- 32GB
- CPU
- ARM Cortex A72 (Quad-Core Up to 1.8 GHz)
- Ports
- 48 x Gigabit Ethernet PoE+ Ports RJ45 (30 W, 802.3at) | 4 x SFP 50 GbE WAN | 1 x USB-C | 1 x USB-A | 1 x RJ45 LAN OOBM port
- Certifications
- EN, FCC, ICES, VCCI, UL, CSA, IEC, CAN
- Size of RAM
- 8 GB DDR4
Tech Specs
- Latency
- 1Gbps 2.28μSec | 10Gbps 1.46μSec | 25Gbps 1.90μSec | 50Gbps 3.49μSec
- Layer Services Supported
- Layer 2, Layer 3, Layer 4
- Weight
- 6.02 Kg
Powering
- Power Supply Type
- Internal
- Input Power
- JL670A PSU (110V‑120V/208V‑240V) | JL086A PSU (100V‑240V) | JL087A PSU (110V‑240V)
- Max power consumption
- With JL086A PSU (Idle 70W, 100% Traffic Rate 90W) | With JL087A PSU (Idle 71W, 100% Traffic Rate 88W) | With JL670A PSU (Idle 73W, 100% Traffic Rate 96W)
PoE-out
- PoE Capability
- 1440W
