Mikrotik (CRS125-24G-1S-2HnD-IN) Router Switch - 24 x Gigabit Ethernet ports, 1 x SFP Port
Key Features
24 x Gigabit Ethernet Ports: Supports high-speed wired connections, ideal for enterprise networks, offering robust and fast data transfers across multiple devices.
1 x SFP Port for Fiber Connectivity: Provides flexible fiber optic options, ensuring smooth data transfer over long distances in professional and industrial settings.
Dual Functionality as Router and Switch: This device merges routing and switching capabilities, making it versatile for both small to medium business networks and data centers.
Integrated Wireless Access Point: Features built-in 2.4 GHz wireless support, allowing for seamless wireless networking alongside wired connections.
Powerful Operating System: Runs on MikroTik’s RouterOS, offering advanced management tools, routing protocols, firewall protection, and wireless configurations for efficient network control
Specifications
Q&A
Warranty
wholesale buying guide
General
- Certifications
- CE, FCC, EAC, ROHS
- Storage size
- 128 MB
- Operating System
- RouterOS
- CPU
- AR9344
- Wireless 2.4 GHz standards
- 802.11b/g/n
- Antenna gain dBi for 2.4 GHz
- 4
- Wireless 2.4 GHz generation
- Wi-Fi 4
- Ambient temperature
- -30°C to 60°C
- CPU core count
- 1
- Ports
- 24 x Gigabit Ethernet ports | 1 x SFP Port
- Size of RAM
- 128 MB
Tech Specs
- Cooling type
- Passive
- RouterOS license
- 5
- CPU nominal frequency
- 600 MHz
- PoE in
- Passive PoE
- Wireless 2.4 GHz number of chains
- 2
- Max Transmit power of 2.4 GHz
- 29 dBm
Powering
- Number of DC inputs
- 2 (DC jack, PoE-IN)
- DC jack input Voltage
- 8-28 V
- Max power consumption
- 19 W
- PoE in input Voltage
- 8-28 V
Peripherals
- Number of USB ports
- 1
- Serial console port
- RJ45
- USB slot type
- microUSB type AB
- USB Power Reset
- YES
- Max USB current (A)
- 1
