Key Features
The GPEN21 is a cost-effective and versatile device with passive or 802.3af/at PoE input options, making it suitable for use in a variety of network environments. With a tested ambient temperature range of -20°C to 70°C, it can operate in extreme conditions. The device features two DC inputs (DC Jack, PoE-IN) with the input voltage range of 12-57 V and supports up to 30W of maximum power consumption. The GPEN21 comes with two 10/100/1000 Ethernet ports, one 1G Ethernet port with PoE-out, and one SFP port. It is CE, EAC, and ROHS certified, has an IP20 rating.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Ambient temperature
- -20°C to 70°C
- Certifications
- CE, EAC, ROHS
- Switch chip model
- 88E6341
- Input voltage
- 12 - 57 V, Passive or 802.3af/at
- Number of DC inputs
- 2 (DC jack, PoE-IN)
- DC jack input Voltage
- 12-57 V
- Max power consumption
- 30 W
- Max power consumption without attachments
- 3 W
- Cooling type
- Passive
- PoE in
- 802.3af/at
- PoE in input Voltage
- 12-57 V
- PoE-out ports
- Ether2
- PoE out
- Passive PoE up to 57V
- Max out per port output (input 18-30 V)
- 850 mA
- Max out per port output (input 30-57 V)
- 625 mA
- Max total out (A)
- 850 mA
- 10/100/1000 Ethernet ports
- 2
- Number of 1G Ethernet ports with PoE-out
- 1
- Number SFP Ports
- 1
- Output Voltage
- Yes, Passive PoE up to 57 V
- Touchscreen
- Yes
- IP
- IP20
