Mikrotik KNOT IoT Gateway - Wireless for Home and Office, 2 x Fast Ethernet, PoE in and PoE out, 2.4 GHz Band support
Key Features
- IoT Gateway Functionality: The Mikrotik KNOT IoT Gateway serves as a versatile gateway for Internet of Things (IoT) devices, providing seamless connectivity for various smart devices in both home and office environments.
- Dual Ethernet Ports: With 2 x Fast Ethernet ports, this gateway allows for reliable wired connections to devices such as computers, printers, and IoT sensors, ensuring stable data transmission.
- Power over Ethernet (PoE) Support: Featuring both PoE in and PoE out capabilities, this device simplifies installation by enabling power and data transmission over a single Ethernet cable, reducing the need for additional power outlets.
- 2.4 GHz Band Support: With support for the 2.4 GHz frequency band, this gateway ensures compatibility with a wide range of wireless devices, providing reliable connectivity for IoT devices operating in this frequency range.
- Wireless Access Point Functionality: In addition to its gateway capabilities, this device can also function as a wireless access point, offering wireless connectivity for smartphones, tablets, and other Wi-Fi-enabled devices in the home or office.
Specifications
Overview
Frequently Compared
Q&A
Warranty
wholesale buying guide
General
- Wireless 2.4 GHz Max data rate
- 300 Mbit/s
- Wireless 2.4 GHz standards
- 802.11b/g/n
- Wireless 2.4 GHz generation
- Wi-Fi 4
- Antenna gain dBi for 2.4 GHz
- 1.5
- Ports
- 2 x Fast Ethernet | 1 x (Nano SIM) | 1 x microUSB type AB | PoE in and PoE out | Serial RS485
- Operating System
- RouterOS
- Ambient temperature
- -40C to +70C
- Certifications
- CE, FCC, IC, EAC, ROHS
Tech Specs
- RouterOS license
- 4
- Storage size
- 128 MB
- Storage type
- NAND
- MTBF
- Approximately 100'000 hours at 25C
- Architecture
- MIPSBE
- CPU nominal frequency
- 650 MHz
- Size of RAM
- 64 MB
- IP
- IP20
- CPU
- QCA9531
- Max Transmit power of 2.4 GHz
- 22 dBm
- Wireless 2.4 GHz number of chains
- 2
- CPU core count
- 1
Powering
- Cooling type
- Passive
- PoE in
- 802.3af/at
- Max power consumption without attachments
- 5 W
- DC jack input Voltage
- 12-57 V
- Max power consumption
- 18 W
- MicroUSB input Voltage
- 5 V
- Number of DC inputs
- 3 (MicroUSB, DC jack, PoE-IN)
- PoE in input Voltage
- 18-57 V
PoE-out
- PoE-out ports
- Ether2
- PoE out
- Passive PoE up to 57V
- Total output power
- 12
