MikroTik Netpower 16P (CRS318-16P-2S+OUT) Switch - Outdoor, 16 x Gigabit Ethernet ports, 16 x 1G Ethernet ports with PoE-out, 2 x SFP+ ports
Key Features
Comprehensive Port Options: Features 16 Gigabit Ethernet ports, along with 2 SFP+ ports, providing extensive connectivity for various networking needs, from simple home setups to complex enterprise solutions.
Power over Ethernet (PoE) Capability: Each of the 16 Ethernet ports supports PoE-out, allowing you to power devices like IP cameras, wireless access points, and VoIP phones directly through the network cable, simplifying installation and reducing the need for additional power supplies.
Designed for Outdoor Use: Built specifically for outdoor applications, the MikroTik Netpower 16P is housed in a rugged enclosure that protects against environmental factors, ensuring reliable performance in varying weather conditions.
High-Speed Fiber Connectivity: The inclusion of 2 SFP+ ports enables high-speed fiber connections, facilitating data transfer rates up to 10 Gbps for improved network efficiency and speed, especially beneficial in high-demand environments.
User-Friendly Management: MikroTik's intuitive RouterOS provides robust management features, allowing for easy configuration and monitoring of network performance, ensuring seamless operation and maintenance for both novice and experienced users
Specifications
Q&A
Warranty
wholesale buying guide
General
- CPU
- 98DX226S
- Operating System
- RouterOS / SwitchOS
- Ambient temperature
- -40°C to 70°C
- CPU core count
- 1
- Storage size
- 16 MB
- Ports
- 16 x Gigabit Ethernet ports | 16 x 1G Ethernet ports with PoE-out | 2 x SFP+ ports
- Certifications
- CE, EAC, ROHS
- Size of RAM
- 256 MB
Tech Specs
- CPU nominal frequency
- 800 MHz
- RouterOS license
- 5
- Cooling type
- Passive
Powering
- Number of DC inputs
- 2 (DC jack)
- DC jack input Voltage
- 18-30 V / 48-57 V
- Max power consumption
- 316 W
- Max power consumption without attachments
- 16 W
PoE-out
- PoE in
- 802.3af/at
- PoE-out ports
- Ether1-Ether16
- Max out per port output (input 18-30 V)
- 1.1 A
- Max out per port output (input 30-57 V)
- 0.6 A
- Max total out (A)
- 2.8A (18V-30V) & 1.4A (48V-57V) x2 A
