Mikrotik R11e-5HacD - 5Ghz miniPCI-express INTERFACES
Express Shipping
out of 5 stars
Key Features
R11e-5HacD is a miniPCIe card with dual MMCX connectors, compatible with the 802.11a/n/ac standards. It features a QCA9882 chipset, an output power of 27dBm, and a maximum data rate of 867 Mbit/s. It can be used both indoors and outdoors and is certified by FCC and IC. With its small size, low power consumption (4W), and broad operating temperature range (-40°C to 70°C), the R11e-5HacD is an ideal solution for wireless applications that require high performance, reliability, and cost-effectiveness. making it an excellent choice for various types of wireless projects.
Specifications
Q&A
Warranty
wholesale buying guide
General
- 5GHz
- Yes
- Antenna header count
- 2
- vPro Support
- Yes
- Touchscreen
- Yes
- Chipset
- QCA9882
- Connector
- 2x MMCX
- Format
- miniPCI-e
- Max power consumption
- 4 W
- Output power
- 27dBm
- Storage size
- 4 KB
- Storage type
- FLASH
- Wi-Fi generation
- Wi-Fi 5
- WiFi speed
- AC900
- Wireless 5 GHz Max data rate
- 867 Mbit/s
- Wireless 5 GHz chip model
- QCA9882
- Wireless 5 GHz generation
- Wi-Fi 5
- Wireless 5 GHz number of chains
- 2
- Wireless 5 GHz standards
- 802.11a/n/ac
- Wireless standards
- 802.11a/n/ac
- 6MBit/s
- 27
- 54MBit/s
- 23
- MCS0
- 26
- MCS7
- 23
- MCS9
- 19
- Ambient temperature
- -40°C to 70°C
- Certifications
- FCC, IC
