Mikrotik SXT LTE6 kit-US SXTR&EP06-A - LTE/5G OUTDOOR WIRELESS
MPN #SXTR&EP06-A
Key Features
Key features for the SXT LTE6 kit-US include a MIPSBE architecture with a QCA9531 CPU at 650 MHz and 1 CPU core. The router has 64 MB of RAM and 16 MB of FLASH storage. It also features a passive cooling type and can support PoE in and out with an input voltage of 12-57 V. The LTE modem has a Category 6 and can provide download speeds up to 300Mbit/s and upload speeds up to 50Mbit/s. The router has 2 Ethernet ports, 2 SIM card slots, and 1 MiniPCI-e slot. It is also equipped with a mode button and has been tested in temperatures ranging from -40°C to 60°C.
Specifications
Overview
Frequently Compared
Q&A
Warranty
wholesale buying guide
General
- Ambient temperature
- -40°C to 60°C
- Architecture
- MIPSBE
- CPU
- QCA9531
- CPU core count
- 1
- CPU nominal frequency
- 650 MHz
- Switch chip model
- QCA9531
- RouterOS license
- 3
- Operating System
- RouterOS
- Size of RAM
- 64 MB
- L3 Cache
- 16 MB
- Storage type
- FLASH
- MTBF
- Approximately 200'000 hours at 25C
- Number of DC inputs
- 1 (PoE-IN)
- Max power consumption
- 21 W
- Max power consumption without attachments
- 5 W
- Cooling type
- Passive
- PoE in
- 802.3af/at
- PoE in input Voltage
- 12-57 V
- PoE-out ports
- Ether2
- PoE out
- Passive PoE up to 57V
- Max out per port output (input 18-30 V)
- 600 mA
- Max out per port output (input 30-57 V)
- 400 mA
- Max total out (A)
- 600 mA
- Total output current
- 600mA
- 3G Category
- R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
- 3G bands
- 2 (1900MHz) / 5 (850MHz) / 4 (1700MHz)
- LTE Category
- 6 (300Mbit/s Downlink, 50Mbit/s Uplink)
- MIMO DL
- 2x2
- LTE FDD bands
- 2 (1900MHz) / 4 (1700MHz) / 5 (850MHz) / 7 (2600MHz) / 12 (700MHz) / 13 (700 MHz) / 25 (1900MHz) / 26 (850MHz) / 30 (2300 MHz) / 66 (1700MHz) / 29 (700 MHz)
- 10/100 Ethernet ports
- 2
- Number of SIM slots
- 2 Modem (Micro SIM)
- MiniPCI-e slots
- 1
- Touchscreen
- Yes
