Ruijie (RG-ES126S-P V2) Unmanaged Switch - 24 x 10/100 Base-X PoE+ ports, 2 x Gigabit Ethernet Base-T ports
Key Features
24 x 10/100 Base-X PoE+ Ports: Power and connect multiple devices like IP cameras and wireless access points efficiently with these PoE+ ports, delivering up to 30W per port.
2 x Gigabit Ethernet Base-T Uplink Ports: High-speed uplink for smooth data transfer and network expansion, ensuring seamless connectivity for more demanding applications.
Plug-and-Play Functionality: This unmanaged switch offers hassle-free installation with zero configuration required, making it ideal for small to medium-sized networks.
Robust PoE Power Distribution: The PoE+ ports provide both power and data over Ethernet cables, simplifying installation and reducing the need for additional power outlets.
Durable and Compact Design: With a solid build and compact design, it delivers reliable performance in various networking environments, ensuring stability and uptime for critical devices.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Tested ambient temperature
- 0°C to 45°C (32°F to 109°F)
- Switching Bandwidth
- 8.8 Gbps
- Certifications
- CE, ROHS
- Ports
- 24 x 10/100 Base-X PoE+ ports | 2 x Gigabit Ethernet Base-T ports | 1 x Combo port
Tech Specs
- Port Surge
- 6 kV
Powering
- Power Supply
- 100V AC to 240V AC, 4A
- Power Consumption
- 220 Watts
PoE-out
- PoE Capability
- 370 Watts
