Ruijie (RG-ES206GC-P) Switch - 6 x Gigabit Ethernet port Base-T, 4 x PoE+ ports
Key Features
Flexible PoE+ Capabilities: Featuring 4 x PoE+ ports, this switch efficiently powers devices such as IP cameras and wireless access points, facilitating a streamlined setup with reduced cabling requirements.
High-Speed Data Transfer: Equipped with 6 x Gigabit Ethernet Base-T ports, the switch ensures rapid data transmission, making it suitable for bandwidth-intensive applications and a seamless network experience.
Compact and Efficient Design: The space-saving design of the switch is ideal for small office environments or limited spaces, allowing for easy installation without compromising on performance.
Robust Networking Solution: Designed for reliability, this switch provides stable connectivity, making it a dependable choice for various networking tasks in both home and small business settings.
User-Friendly Management: The Ruijie switch supports straightforward management features, enabling easy monitoring and configuration to suit specific network needs, ensuring hassle-free operation for users of all skill levels.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Ports
- 6 x Gigabit Ethernet Port Base-T | 4 x PoE+ Ports | 1 x Combo SFP
- Switching Bandwidth
- 12 Gbps
- Tested ambient temperature
- 0°C to 40°C
Tech Specs
- FAN
- Fanless
- PoE
- 54W, IEEE 802.3at / IEEE 802.3af
- Port Surge
- 4 kV
- Weight
- 0.79 kg
Powering
- Power Supply
- 54V DC adapter, 1.1A
PoE-out
- PoE Capability
- 54W
