TP LINK TL-SG1008P V7 Switch - 8 x Gigabit Ethernet ports, AUTO MDI/MDIX, PoE-out
Key Features
8 Gigabit Ethernet Ports: Delivers high-speed connectivity across all 8 ports, ideal for handling large data transfers, streaming, and network-intensive applications.
PoE-Out Capability: Four of the ports support Power over Ethernet (PoE-out), enabling you to power devices such as IP cameras, access points, and VoIP phones directly through the network cables.
Auto MDI/MDIX: Simplifies setup by automatically adjusting for crossover or straight-through cables, making network expansion easier without needing specialized cables.
Plug and Play: No configuration required, offering an effortless setup process, making it perfect for users needing quick deployment in small or home offices.
Energy-Efficient Design: Integrated with energy-saving technology, this switch helps reduce power consumption, adjusting power usage based on connection status and activity levels
Specifications
Q&A
Warranty
wholesale buying guide
General
- Certifications
- CE, FCC, RoHS
- Ports
- 8 x Gigabit Ethernet ports, AUTO MDI/MDIX
- Switching Bandwidth
- 16 Gbps
- Ambient temperature
- 0–40 ℃ (32–104 ℉)
Tech Specs
- Fan Quantity
- Fanless
- Packet Forwarding Rate
- 11.904 Mpps
Powering
- External Power Supply
- External Power Adapter(Output: 53.5VDC / 1.31A)
- Max power consumption
- 4.7 W (220/50 Hz no PD connected) | 74.39 W (220/50 Hz with 64 W PD connected)
