UNV ColorHunter Wise-ISP Fixed Dome Camera - 4MP (2688 x 1520), 1 1.8″ 4.0 Megapixel Progressive Scan CMOS Sensor, Fixed 4.0mm @ F1.0 Lens, Outdoor, PoE Connect power
Key Features
4MP High-Resolution Imaging: Delivers sharp and detailed 4MP (2688 x 1520) video quality with a 1/1.8" CMOS sensor.
24/7 Full-Color Night Vision: Features ColorHunter and Wise-ISP technology for vibrant full-color images even in low-light environments.
Advanced WDR & Audio Recording: Equipped with 120dB Wide Dynamic Range for clear images in varying lighting and built-in microphone for audio capture.
Rugged Outdoor Durability: IP67 and IK10-rated, providing water and impact resistance for reliable outdoor performance.
PoE Power & Local Storage: Supports PoE for simplified setup and up to 512GB Micro SD card storage for convenient recording.
Specifications
Overview
Frequently Compared
Q&A
Warranty
wholesale buying guide
General
- Sensor
- 1/1.8″, 4.0 megapixel, progressive scan, CMOS
- Lens
- Fixed 4.0mm@F1.0
- Resolution
- 4MP (2688 x 1520)
- View Angle
- H 89.4° | V 48.2° | D 94.7°
- Basic Event
- Basic Detection ( Cross line, intrusion(based on human body detection), Motion detection, Ultra motion detection, Tampering alarm, Audio Detection) | General Function (Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP authentication)
- Record Audio
- Audio Compression (G 711U, G 711A)
Tech Specs
- Min Illumination
- Colour 0.0003lux (F1.0, AGC ON)
- Shutter Time
- Auto/Manual, 1 ~ 1/100000s
- Angle Adjustment
- Pan (8° to 360°) | Tilt (0° to 68°) | Rotate (10° to 360°)
- DORI
- D (43.4(142.5ft), 62.1(203.6ft)) | O (17.4(57.0ft), 24.8(81.5ft)) | R (8.7(28.5ft), 12.4(40.7ft)) | I (4.3(14.3ft), 6.2(20.4ft))
- Video Compression
- Ultra265, H.265, H.264, MJPEG
- Max Frame Rate
- Main Stream ( 4MP (2688*1520), Max 25fps;4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps) | Sub Stream (720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps)
- Video Bit Rate
- 128 Kbps to 6144Kbps
- Support
- BLC | HLC
- Edge Storage
- Micro SD, up to 512GB
- Ports
- 1 x RJ45 10M/100M Base-TX Ethernet
Powering
- Power method
- DC 12V±25%, PoE (IEEE 802.3af)
- Max power consumption
- 2.8 Watts
