UNV Vandal-resistant IR Fixed Dome Camera - 8MP 4K (3840 x 2160), 1/2.7 Progressive Scan CMOS Sensor, Fixed 4.0 mm @F1.6 Lens, Outdoor, PoE Connect power
Express Shipping
out of 5 stars
Key Features
- 8MP Ultra HD Resolution: Delivers crystal-clear 4K video quality (3840 x 2160) for capturing fine details in security footage.
- Advanced 1/2.7" Progressive CMOS Sensor: Ensures superior image clarity, even in challenging lighting, with a 4.0mm fixed lens at F1.6.
- Smart IR Night Vision: Offers up to 30 meters of night vision with an IR-cut filter that switches automatically, ensuring visibility in total darkness.
- Rugged Design for Outdoor Use: Built to withstand harsh conditions with IP67 weatherproof and IK10 vandal-resistant ratings, ideal for both indoor and outdoor surveillance.
- PoE Connectivity & Storage Options: Supports Power over Ethernet for easy installation, plus up to 256GB Micro SD storage and Ultra 265 compression for efficient video storage.
Specifications
Q&A
Warranty
wholesale buying guide
General
- Sensor
- 1/2.7" 8.0 Megapixel Progressive Scan CMOS
- Night Vision Range
- 30 m IR-cut filter with auto switch (ICR)
- Resolution
- 8MP 4K (3840 x 2160)
- Lens
- Fixed 4.0mm@F1.0
- Basic Event
- Basic Detection (Cross line, intrusion(based on human body detection), motion detection, Ultra motion detection, tampering alarm, audio detection) | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication
- View Angle
- H 91.2° | V 47.9° | D 95.9°
Tech Specs
- Min Illumination
- Support Easystar: Colour 0.005 lux ( F1.6, AGC ON) 0Lux with IR on
- Shutter Time
- Auto/Manual, 1 ~ 1/100000s
- Angle Adjustment
- Pan (8° to 360°) | tilt (0° ~ 68°) | rotate (10° ~360°)
- Wide Dynamic Range
- 120 dB
- DORI
- 2.8mm (D 84 | O 33.6 | R 16.8 | I 8.4) | 4.0mm (D 120 | O 48 | R 24 | I 12)
- Video Compression
- Ultra265, H.265, H.264, MJPEG
- Max Frame Rate
- Main Stream (8MP (3840 x 2160), Max 20fps | 5MP (3072 x 1728), Max 30fps | 4MP (2560 x 1440), Max 30fps | 1080P (1920 x 1080), Max 30fps) - Sub Stream ( 1080P (1920 x 1080), Max 30fps | 720P (1280 x 720), Max 30fps | D1 (720 x 576), Max 30fps | 640 x 360,Max 30fps | 2CIF(704 x 288), Max 30fps)
- Video Bit Rate
- 128 Kbps -16 Mbps
- White Balance
- Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
- Flip
- Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
- Support
- BLC | HLC
- Edge Storage
- Micro SD, up to 256 GB
Powering
- Power method
- DC 12V±25%, PoE (IEEE 802.3af)
- Max power consumption
- 4.5 Watts
