APC GALAXY VS Uninterruptible Power Supply UPS - 384-480VDC External battery system Li-Ion (Lithium Ion) VRLA, 208 V 3 phase, Schneider Electric

Name: APC GALAXY VS Uninterruptible Power Supply UPS - 384-480VDC External battery system Li-Ion (Lithium Ion) VRLA, 208 V 3 phase, Schneider Electric
Brand: APC
Price: 26500.00 USD
Availability: InStock

$ 26500^.00

APC-GVSUPS40KRFS

MPN #GVSUPS40KRFS

Questions⁽²⁾ Answers⁽²⁾

BRAND NEW

Express Shipping

2-6 Days, via DHL, FedEx, EMS, etc.

Reviews

Reliable Uninterruptible Power – Ensures continuous and stable power supply for offices, data centers, and critical infrastructure during outages.
External Li-Ion VRLA Battery System – Equipped with a high-capacity external lithium-ion battery for extended runtime, scalability, and easy maintenance.
208V 3-Phase Output – Provides consistent three-phase power suitable for commercial and industrial applications, protecting sensitive equipment.
Comprehensive Power Protection – Includes surge protection, power conditioning, and electrical safety measures to safeguard connected devices.
Advanced Management by Schneider Electric – Supports smart power monitoring, network management, and emergency backup operations for mission-critical systems.

Package Dimensions

Width: 25.20 in

Height: 66.10 in

Length: 39.00 in

Weight: 250.00 kg

Specifications

Q&A

Warranty

wholesale buying guide

General

Battery Voltage: 384-480VDC
Output Voltage THD: < 1% linear load and < 3% non-linear load
Product or Component Type: Uninterruptible power supply (UPS)
Battery power in VAH: 0 VAh runtime
End of Discharge Battery Voltage: 307 V DC
Output voltage tolerance: +/-1% after 50ms
Maximum Configurable Power in VA: 40 kVA
Main Input Voltage: 208 V 3 phase
Main Output Voltage: 208 V 3 phase
Color: White

Tech Specs

Ambient Air Temperature for Operation: 32…104 °F (0…40 °C)
Bypass type: Built-in Static Bypass
Waveform Type: Sine wave
Crest factor: 2.5
Output Frequency: 50 Hz sync to mains 60 Hz sync to mains 50 Hz +/- 0.1 % for 50 Hz nominal not synced 60 Hz +/- 0.1 % for 60 Hz nominal not synced
Battery Type: External battery system Li-Ion (Lithium Ion) VRLA
Output voltage tolerance: +/-1% after 50ms
Load power factor: From 0.7 leading to 0.7 lagging without any derating
Heat dissipation: 7756 Btu/h
IP degree of protection: IP21
Control panel: Touch Screen LCD User Interface
Standards: IEC 62040-1-1 IEC 62040-2 UL 1778 5th edition FCC Part 15 class A IEC 60721-4-2 Level 2M2 UL 924 Listed
Input Total Harmonic Distortion: Less than 3% for full load
Maximum Input Current per Phase: 143 A
Efficiency at full load: 177...239 V 208 V
Dimensions: L (33.3 in) x W (20.5 in) x H (58.5 in)
Provided Equipment: Dust filter EcoStruxure IT ready (UPS) Installation guide Integrated network management Power modules ship installed Start-Up Service
Presentation: Highly efficient, easy-to-deploy 40kW, 208V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5x8 start-up service and one additional power module for N+1 redundancy.
Overload Operation: 10 minutes @ 125% and 60 seconds @ 150%
Max Configurable Power (Watts): 40 kW
Maximum Short Circuit Withstand (Icw): 65 kA
Input Frequency: 40 - 70 Hz
Lead time: Usually Ships within 2 Weeks
Acoustic level: 68 dBA
Storage Relative Humidity: 10…80 % non-condensing
Ambient Air Temperature for Storage: -13…131 °F (-25…55 °C)
Operating altitude: 0...3300 ft
Relative Humidity: 0…95 % non-condensing
