APC GALAXY VS Uninterruptible Power Supply UPS - 480-576VDC External battery system Li-Ion (Lithium Ion) VRLA, 400 V 3 phase, Schneider Electric, 120 kVA
$ 24500.00
Key Features
Robust 120 kVA Power Capacity – Provides reliable 400 V 3-phase output, designed to handle the demanding loads of data centers, offices, and industrial operations.
-
Flexible External Battery Support – Compatible with 480–576 VDC Li-Ion and VRLA battery systems, delivering scalable backup power and extended runtime options.
-
Advanced Power Protection – Offers surge suppression, power conditioning, and backup solutions, ensuring consistent uptime for critical IT and electrical equipment.
-
Smart Energy & Network Management – Integrated remote monitoring and intelligent control features enable optimized performance and efficient power management.
-
Enterprise-Grade Reliability – Engineered by Schneider Electric, this UPS ensures emergency power, operational safety, and stable energy delivery for professional environments.
Package Dimensions
Width: 39.00 in
Height: 66.10 in
Length: 25.20 in
Weight: 315.00 kg
Specifications
Q&A
Warranty
wholesale buying guide
General
- Maximum Configurable Power in VA
- 120 kVA
- Battery Voltage
- 480-576VDC
- End of Discharge Battery Voltage
- 384 V DC
- Product or Component Type
- Uninterruptible power supply (UPS)
- Battery Type
- External battery system Li-Ion (Lithium Ion) VRLA
- Main Input Voltage
- 400 V 3 phase
- Main Output Voltage
- 400 V 3 phase
- Battery power in VAH
- 0 VAh runtime
- Ambient Air Temperature for Operation
- 32…104 °F (0…40 °C)
- Relative Humidity
- 0…95 % non-condensing
- Operating altitude
- 0...3333 ft
- Ambient Air Temperature for Storage
- -13…131 °F (-25…55 °C)
- Storage Relative Humidity
- 10…80 % non-condensing
- Storage altitude
- 0…50000 ft (0…15240 m)
- Acoustic level
- 65 dBA
- Heat dissipation
- 12509 Btu/h
- IP degree of protection
- IP21
- Control panel
- Touch Screen LCD User Interface
- Color
- White
Tech Specs
- Presentation
- Highly efficient, easy-to-deploy 120kW, 400V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5x8 start-up service. See the battery runtime chart for details.
- Lead time
- Usually Ships within 2 Weeks
- Main Input Voltage
- 380 V 415 V
- Provided Equipment
- Dust filter EcoStruxure IT ready (UPS) Installation guide Integrated network management Power modules ship installed Start-Up Service
- Dimensions
- L (33.3 in) x W (20.5 in) x H (58.5 in)
- Weight
- 278 kg
- Input Frequency
- 40 - 70 Hz
- Efficiency at full load
- 340...460 V 400 V
- Input Total Harmonic Distortion
- Less than 3% for full load
- Load power factor
- From 0.7 leading to 0.7 lagging without any derating
- Input Power Factor at Full Load
- 0.99
- Output Frequency
- 50 Hz sync to mains 60 Hz sync to mains 50 Hz +/- 0.1 % for 50 Hz nominal not synced 60 Hz +/- 0.1 % for 60 Hz nominal not synced
- Crest factor
- 2.5
- Waveform Type
- Sine wave
- Output voltage tolerance
- +/-1% after 50ms
- Overload Operation
- 10 minutes @ 125% and 60 seconds @ 150%
- Standards
- IEC 62040-1-1 IEC 62040-2 IEC 60721-4-2 Level 2M2 OSHPD UL 1778 5th edition
