Mikrotik KNOT LR8 kit RB924iR-2nD-BT5&BG77&R11e-LR8 - IoT GATEWAY SOLUTION FOR LoRa® TECHNOLOGY
$ 238.80
MPN #RB924iR-2nD-BT5&BG77&R11e-LR8
Key Features
The KNOT LR8 kit is a powerful networking solution with a MIPSBE architecture and a QCA9531 CPU running at 650 MHz. It comes with 64 MB of RAM and 128 MB of NAND storage. The device operates on RouterOS and has a RouterOS license of 4. It is capable of up to 300 Mbit/s speeds with its 2.4 GHz wireless frequency and has a gain dBi of 1.5 for its antennas. The LR8 kit also features 2 10/100 Ethernet ports, a miniPCI-e slot, 1 SIM card slot, and 1 USB port. It is designed for temperature ranges from -40°C to 70°C and has passive cooling. It supports PoE-in and has a Max power consumption of 23 W. the KNOT LR8 kit is a reliable and cost-effective networking solution.
Specifications
Overview
Frequently Compared
Q&A
Warranty
wholesale buying guide
General
- Ambient temperature
- -40°C to 70°C
- 11MBit/s
- 22
- Architecture
- MIPSBE
- CPU
- QCA9531
- CPU core count
- 1
- CPU nominal frequency
- 650 MHz
- Switch chip model
- QCA9531
- Operating System
- RouterOS
- Size of RAM
- 64 MB
- MTBF
- Approximately 200'000 hours at 25C
- MicroUSB input Voltage
- 5 V
- Number of DC inputs
- 3 (DC jack, PoE-IN, MicroUSB)
- DC jack input Voltage
- 12-57 V
- Max power consumption
- 23 W
- Max power consumption without attachments
- 5 W
- Cooling type
- Passive
- PoE in
- 802.3af/at
- PoE in input Voltage
- 18-57 V
- PoE-out ports
- Ether2
- PoE out
- 802.3af/at
- Max out per port output (input 18-30 V)
- 650 mA
- Max out per port output (input 30-57 V)
- 450 mA
- Wireless 2.4 GHz Max data rate
- 300 Mbit/s
- Memory Slots
- 2
- Wireless 2.4 GHz standards
- 802.11b/g/n
- Antenna gain dBi for 2.4 GHz
- 1.5
- Wireless 2.4 GHz chip model
- QCA9531
- Wireless 2.4 GHz generation
- Wi-Fi 4
- 10/100 Ethernet ports
- 2
- Number of SIM slots
- 1 Modem (Nano SIM)
- MiniPCI-e slots
- 1
- Serial console port
- RS485
- Number of USB ports
- 1
- USB slot type
- microUSB type AB
- Max USB current (A)
- 1
- vPro Support
- Yes
- vPro Support
- Yes
- Bluetooth
- 5.2
- Bluetooth RF connector type
- uUFL
- IP
- 20
- 1MBit/s
- 22
- 6MBit/s
- 20
- 54MBit/s
- 18
- MCS0
- 20
- MCS7
- 16
- RouterOS license
- 4
- Storage size
- 128 MB
- Storage type
- NAND
- Certifications
- CE, EAC, ROHS
