Mikrotik LHG LTE kit-US RBLHGR&R11e-LTE-US - LHG 3G/4G/LTE HIGH GAIN ANTENNA
MPN #RBLHGR&R11e-LTE-US
Key Features
The LHG LTE kit-US (RBLHGR&R11e-LTE-US) is a reliable and high-performance wireless router designed for easy installation and use. It features a MIPSBE architecture with a powerful QCA9531 CPU core clocked at 650 MHz. With a compact design measuring 391 x 391 x 227 mm, it comes with 64 MB RAM and 16 MB storage. It supports 3G and LTE connectivity with a maximum download speed of 150Mbps and 50Mbps upload speed. Other key features include one Ethernet port, one SIM slot, a Mode button, and a passive cooling system. It is also certified by CE, EAC, and ROHS.
Specifications
Overview
Q&A
Warranty
wholesale buying guide
General
- Architecture
- MIPSBE
- CPU
- QCA9531
- CPU core count
- 1
- CPU nominal frequency
- 650 MHz
- RouterOS license
- 3
- Operating System
- RouterOS
- L3 Cache
- 16 MB
- Storage type
- FLASH
- Number of DC inputs
- 1 (PoE-IN)
- Max power consumption
- 6 W
- Cooling type
- Passive
- PoE in
- 802.3af/at
- PoE in input Voltage
- 12-57 V
- 3G Category
- R7 (21Mbps Downlinks, 5.76Mbps Uplink) / R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
- 3G bands
- 2 (1900MHz) / 5 (850MHz)
- LTE Category
- 4 (150Mbps Downlink, 50Mbps Uplink)
- LTE FDD bands
- 2 (1900MHz) / 4 (1700MHz) / 5 (850MHz) / 12 (700MHz)
- 10/100 Ethernet ports
- 1
- MiniPCI-e slots
- 1
- Touchscreen
- Yes
- Ambient temperature
- -40°C to 60°C
- Certifications
- CE, EAC, ROHS
- MTBF
- Approximately 200'000 hours at 25C
- Size of RAM
- 64 MB
- Dimensions
- 391 x 391 x 227 mm
- Color
- Silver

$190.80
Mikrotik LHG LTE kit-US RBLHGR&R11e-LTE-US - LHG 3G/4G/LTE HIGH GAIN ANTENNA
Feature | Included |
---|---|
Review |
Feature | Included |
---|---|
Architecture | MIPSBE |
CPU | QCA9531 |
CPU core count | 1 |
CPU nominal frequency | 650 MHz |
Dimensions | 391 x 391 x 227 mm |
RouterOS license | 3 |
Operating System | RouterOS |
Size of RAM | 64 MB |
L3 Cache | 16 MB |
Storage type | FLASH |
MTBF | Approximately 200'000 hours at 25C |
Number of DC inputs | 1 (PoE-IN) |
Max power consumption | 6 W |
Cooling type | Passive |
PoE in | 802.3af/at |
PoE in input Voltage | 12-57 V |
3G Category | R7 (21Mbps Downlinks, 5.76Mbps Uplink) / R8 (42.2Mbps Downlink, 5.76Mbps Uplink) |
3G bands | 2 (1900MHz) / 5 (850MHz) |
LTE Category | 4 (150Mbps Downlink, 50Mbps Uplink) |
LTE FDD bands | 2 (1900MHz) / 4 (1700MHz) / 5 (850MHz) / 12 (700MHz) |
10/100 Ethernet ports | 1 |
MiniPCI-e slots | 1 |
Touchscreen | Yes |
Ambient temperature | -40°C to 60°C |
Color | Silver |
Certifications | CE, EAC, ROHS |
2G Category | No |
2G bands | No |
LTE TDD bands | No |
IP | No |
Switch chip model | No |
Max power consumption without attachments | No |
PoE-out ports | No |
PoE out | No |
Max out per port output (input 18-30 V) | No |
Max out per port output (input 30-57 V) | No |
Max total out (A) | No |
Number of SIM slots | No |

$214.80
Mikrotik LHG LTE kit RBLHGR&R11e-LTE - LHG 2G/3G/4G/LTE OUTDOOR WIRELESS
Feature | Included |
---|---|
Review |
Feature | Included |
---|---|
Architecture | Yes |
CPU | Yes |
CPU core count | Yes |
CPU nominal frequency | Yes |
Dimensions | Yes |
RouterOS license | Yes |
Operating System | Yes |
Size of RAM | Yes |
L3 Cache | Yes |
Storage type | Yes |
MTBF | Yes |
Number of DC inputs | Yes |
Max power consumption | Yes |
Cooling type | Yes |
PoE in | Yes |
PoE in input Voltage | Yes |
3G Category | R7 (21Mbps Downlinks, 5.76Mbps Uplink) |
3G bands | 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz) |
LTE Category | Yes |
LTE FDD bands | 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) |
10/100 Ethernet ports | Yes |
MiniPCI-e slots | Yes |
Touchscreen | Yes |
Ambient temperature | -40°C to 50°C |
Color | Yes |
Certifications | Yes |
2G Category | Class12 |
2G bands | 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) |
LTE TDD bands | 38 (2600MHz) / 40 (2300MHz) |
IP | IP54 |
Switch chip model | No |
Max power consumption without attachments | No |
PoE-out ports | No |
PoE out | No |
Max out per port output (input 18-30 V) | No |
Max out per port output (input 30-57 V) | No |
Max total out (A) | No |
Number of SIM slots | No |
Feature | Included |
---|---|
Review |
Feature | Included |
---|---|
Architecture | Yes |
CPU | Yes |
CPU core count | Yes |
CPU nominal frequency | Yes |
Dimensions | 140 x 140 x 103 mm |
RouterOS license | Yes |
Operating System | Yes |
Size of RAM | Yes |
L3 Cache | Yes |
Storage type | Yes |
MTBF | Yes |
Number of DC inputs | Yes |
Max power consumption | 22 W |
Cooling type | Yes |
PoE in | Yes |
PoE in input Voltage | Yes |
3G Category | R7 (21Mbps Downlinks, 5.76Mbps Uplink) |
3G bands | 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz) |
LTE Category | Yes |
LTE FDD bands | 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) |
10/100 Ethernet ports | 2 |
MiniPCI-e slots | Yes |
Touchscreen | Yes |
Ambient temperature | -40°C to 50°C |
Color | No |
Certifications | Yes |
2G Category | Class12 |
2G bands | 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) |
LTE TDD bands | 38 (2600MHz) / 40 (2300MHz) |
IP | IP54 |
Switch chip model | QCA9531 |
Max power consumption without attachments | 5 W |
PoE-out ports | Ether2 |
PoE out | Passive PoE up to 57V |
Max out per port output (input 18-30 V) | 600 mA |
Max out per port output (input 30-57 V) | 400 mA |
Max total out (A) | 600 mA |
Number of SIM slots | 2 Modem (Micro SIM) |
Products | ![]() $190.80 Mikrotik LHG LTE kit-US RBLHGR&R11e-LTE-US - LHG 3G/4G/LTE HIGH GAIN ANTENNA | ||
---|---|---|---|
Reviews | |||
Review | |||
Features | |||
Architecture | MIPSBE | Included in | Included in Essential |
CPU | QCA9531 | Included in | Included in Essential |
CPU core count | 1 | Included in | Included in Essential |
CPU nominal frequency | 650 MHz | Included in | Included in Essential |
Dimensions | 391 x 391 x 227 mm | Included in | 140 x 140 x 103 mm |
RouterOS license | 3 | Included in | Included in Essential |
Operating System | RouterOS | Included in | Included in Essential |
Size of RAM | 64 MB | Included in | Included in Essential |
L3 Cache | 16 MB | Included in | Included in Essential |
Storage type | FLASH | Included in | Included in Essential |
MTBF | Approximately 200'000 hours at 25C | Included in | Included in Essential |
Number of DC inputs | 1 (PoE-IN) | Included in | Included in Essential |
Max power consumption | 6 W | Included in | 22 W |
Cooling type | Passive | Included in | Included in Essential |
PoE in | 802.3af/at | Included in | Included in Essential |
PoE in input Voltage | 12-57 V | Included in | Included in Essential |
3G Category | R7 (21Mbps Downlinks, 5.76Mbps Uplink) / R8 (42.2Mbps Downlink, 5.76Mbps Uplink) | R7 (21Mbps Downlinks, 5.76Mbps Uplink) | R7 (21Mbps Downlinks, 5.76Mbps Uplink) |
3G bands | 2 (1900MHz) / 5 (850MHz) | 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz) | 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz) |
LTE Category | 4 (150Mbps Downlink, 50Mbps Uplink) | Included in | Included in Essential |
LTE FDD bands | 2 (1900MHz) / 4 (1700MHz) / 5 (850MHz) / 12 (700MHz) | 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) | 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) |
10/100 Ethernet ports | 1 | Included in | 2 |
MiniPCI-e slots | 1 | Included in | Included in Essential |
Touchscreen | Yes | Included in | Included in Essential |
Ambient temperature | -40°C to 60°C | -40°C to 50°C | -40°C to 50°C |
Color | Silver | Included in | Not included in Essential |
Certifications | CE, EAC, ROHS | Included in | Included in Essential |
2G Category | Not included in Basic | Class12 | Class12 |
2G bands | Not included in Basic | 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) | 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) |
LTE TDD bands | Not included in Basic | 38 (2600MHz) / 40 (2300MHz) | 38 (2600MHz) / 40 (2300MHz) |
IP | Not included in Basic | IP54 | IP54 |
Switch chip model | Not included in Basic | Not included in | QCA9531 |
Max power consumption without attachments | Not included in Basic | Not included in | 5 W |
PoE-out ports | Not included in Basic | Not included in | Ether2 |
PoE out | Not included in Basic | Not included in | Passive PoE up to 57V |
Max out per port output (input 18-30 V) | Not included in Basic | Not included in | 600 mA |
Max out per port output (input 30-57 V) | Not included in Basic | Not included in | 400 mA |
Max total out (A) | Not included in Basic | Not included in | 600 mA |
Number of SIM slots | Not included in Basic | Not included in | 2 Modem (Micro SIM) |
Choose your plan | View Product | View Product |
