Ubiquiti(UAP-AC-EDU) Access Point - UAP AC EDU 802.11ac Dual-Radio Wireless AP with Public Address
Key Features
- Dual-Radio Wireless Connectivity: The Ubiquiti UAP-AC-EDU features advanced 802.11ac technology for high-performance dual-radio wireless connectivity on both 2.4GHz and 5GHz bands.
- Integrated Public Address System: Uniquely equipped with a built-in PA system, this access point facilitates clear and loud audio output, making it ideal for announcements and communication in educational institutions, large venues, or businesses.
- Dual Ethernet Ports: With dual Ethernet ports, the UAP-AC-EDU offers flexibility in deployment and seamless integration into existing network infrastructures, supporting both data connectivity and Power over Ethernet (PoE).
- UniFi Controller Compatibility: Integrated with the UniFi Controller software, this access point allows for centralized management, making configuration, monitoring, and maintenance of multiple devices in the network convenient.
- Versatile Mounting Options: Supporting various mounting options, including ceiling and wall mounts, the UAP-AC-EDU provides deployment flexibility for different environments.
- Security Features: The access point incorporates advanced security features, including WPA and WPA2 encryption, to protect the wireless network from unauthorized access and ensure the privacy of transmitted data.
Specifications
Overview
Frequently Compared
Q&A
Warranty
wholesale buying guide
genral
- Networking interface
- Dual-Band Wi-Fi / Gigabit Ethernet
- Ports
- 2 x 10/100/1000 Ethernet Ports 1 x USB 2.0 Port
- Antennas
- 3 x Dual-Band Antennas, 2.4 GHz: 3 dBi, 5 GHz: 3 dBi
- Wi-Fi Standards
- 802.11 a/b/g/n/ac
- Power method
- Passive Power over Ethernet (48V), 803.2at Supported (Supported Voltage Range: 44 to 57VDC)
- Power Supply
- 48V, 0.5A PoE Gigabit Adapter*
- Max. TX power
- 2.4 GHz: 22 dBm; 5 GHz: 22 dBm
- Wireless Security
- WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
- Mounting
- Wall/Ceiling (Kits Included)
- Max power consumption
- 20W
- Concurrent clients
- 200+
- VLAN
- 802.1Q
Tech Specs
- Dimensions
- 287.5 x 287.5 x 125.9 mm (11.32 x 11.32 x 4.96")
- Weight
- 1.820 kg (4.012 lb)
- BSSID
- Up to Four per Radio
- Operating Temperature
- -10 to 70° C (14 to 158° F)
- Operating Humidity
- 5 to 95% Noncondensing
- Advanced QoS
- Per-User Rate Limiting
- Guest traffic isolation
- Supported
- Certifications
- FCC, IC
