UNV ColorHunter Wise-ISP Fixed Bullet Camera - 4MP (2688 x 1520), 1/1.8″ 4.0 megapixel Progressive Scan CMOS Sensor, Fixed 4.0mm @ F1.0 Lans, Outdoor, PoE Connect power

UNV-IPC2314LE-ADF28(40)KM-WP

MPN #IPC2314LE-ADF28(40)KM-WP

Questions(2) Answers(2)
UNV
BRAND NEW

Express Shipping

2-6 Days, via DHL, FedEx, EMS, etc.
Reviews

Reviews

out of 5 stars

Key Features

  • High-Quality 4MP Resolution: Provides clear, detailed footage with a 4MP (2688 x 1520) resolution for superior image clarity.

  • Advanced Sensor Technology: Equipped with a 1/1.8″ 4.0MP Progressive Scan CMOS sensor for excellent low-light performance.

  • Warm Light for Enhanced Night Vision: Offers up to 30m (98ft) warm light range, ensuring detailed color images even in darkness.

  • Reliable Power Over Ethernet (PoE): Supports PoE for efficient power and data transmission via a single Ethernet cable, simplifying installation.

  • Audio Recording Capability: Features G.711U/G.711A audio compression for high-quality audio recording in surveillance footage.

General

Sensor
1/1.8″, 4.0 megapixel, progressive scan, CMOS
View Angle
H 110.4° | V 60.5° | D 115.2°
Resolution
4MP (2688 x 1520)
Warm Light Range
Up to 30m (98ft)
Lens
Fixed 4.0mm@F1.0
Basic Event
Basic Detection (Cross line, intrusion(based on human body detection),Motion detection, Ultra motion detection, Tampering alarm, Audio Detection) | General Function ( Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP authentication)
Record Audio
Audio Compression (G.711U, G.711A)

Tech Specs

Min Illumination
Colour 0.0003lux (F1.0, AGC ON)
Shutter Time
Auto/Manual, 1 ~ 1/100000s
Angle Adjustment
Pan (0° to 360°) | tilt (0° to 90°) | Rotate (0° to 360°)
DORI
D (43.4(142.5ft), 62.1(203.6ft)) | O (17.4(57.0ft), 24.8(81.5ft)) | R (8.7(28.5ft), 12.4(40.7ft)) | I (4.3(14.3ft)) | 6.2(20.4ft)
Warm Light Range
Up to 30m (98ft)
Video Compression
Ultra265, H.265, H.264, MJPEG
Max Frame Rate
Main Stream (4MP (2688*1520), Max 25fps;4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps) | Sub Stream (720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps)
Record Audio
Audio Compression (G.711U, G.711A)
Edge Storage
Micro SD, up to 512GB
Ports
1 x RJ45 10M/100M Base-TX Ethernet

Powering

Power method
DC 12V±25%, PoE (IEEE 802.3af)
Max power consumption
2.8 Watts
